| COLOUR | Tiger Orange (gloss) | CASSETTE | Shimano CSM6100, 11-51T, black, 12 speed |
|---|
| FRAME | 6061 Alloy, Aluminium Front Triangle with ZS56 Head Tube, ISCG 2 Guide Mounts, proportional chainstays, Shape.it link and 148mm Boost Dropouts | CHAIN | KMC X12, 12 speed |
|---|
| FORK | Marzocchi Bomber Z1, 170mm travel, 44mm offset, air spring, Rail damper, black coating, tapered steerer, 110mm x 15mm Boost, Kabolt axle | CRANKSET | Whyte, forged two-piece cranks, direct mount, alloy 30T narrow/wide chainring, 165mm crank length, Boost, 12 speed, 55mm chainline |
|---|
| REAR SHOCK | Marzocchi Bomber Air piggyback shock, black coating, adjustable rebound and compression, 230 x 57.5mm, custom tuned for Whyte | BOTTOM BRACKET | BSA, cartridge bearings, 73mm |
|---|
| HEADSET | ZS56 upper / lower headset cups for 1 1/18in upper and 1.5in lower with sealed bearings | SEATPOST | TranzX dropper post, 30.9mm, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm drop) |
|---|
| REAR HUB | Alloy, double sealed cartridge bearings, 12mm x 148mm Boost thru axle, MicroSpline freehub, 32 hole | SEAT | Whyte Custom |
|---|
| FRONT HUB | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost thru axle, 32 hole | BAR | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
|---|
| SPOKES | Pillar 14G, black stainless, brass nipples | STEM | Whyte, 35mm extension, 35mm bar bore |
|---|
| RIMS | WTB ST Tough i30 TCS 2.0 System, pinned joint, tubeless ready, 32 hole, 29in (front), 27.5in (rear) | GRIPS | Whyte Enduro lock-on |
|---|
| TYRES | Schwalbe Magic Mary Radial 29 x 2.5in Trail, Super Soft (front); Schwalbe Magic Mary Radial 27.5 x 2.5in, Gravity casing, Soft (rear) | BRAKES FRONT | TRP EVO Comp hydraulic disc brake, four piston, sintered metal pads, 203 x 2.3mm rotor, MMX |
|---|
| SHIFT LEVERS | Shimano M6100 Deore, I-Spec EV, 12 speed | BRAKES REAR | TRP EVO Comp hydraulic disc brake, four piston, sintered metal pads, 203 x 2.3mm rotor, MMX |
|---|
| FRONT MECH | N/A | BRAKE LEVERS | TRP EVO Comp |
|---|
| REAR MECH | Shimano M6100 Deore, SGS, Shadow Plus, 12 speed | PEDALS | Fibre reinforced composite platform |
|---|
| WEIGHT | TBC | | |
|---|
