| COLOUR | Chili red (gloss) | CASSETTE | SRAM XG-1275 Eagle, 10-52T, 12 speed |
|---|
| FRAME | 6061 Alloy, Aluminium Front Triangle with ZS56 Head Tube, ISCG 2 Guide Mounts, proportional chainstays, Shape.it link and 148mm Boost Dropouts | CHAIN | SRAM GX, 12 speed |
|---|
| FORK | RockShox Lyrik Ultimate RC2 29in, 170mm travel, 44mm offset, Linear XL with ButterCups, Charger 3.2 RC2 damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle Ultimate | CRANKSET | SRAM S200, direct mount 30T chainring, DUB, 165mm crank length, 55mm chainline |
|---|
| REAR SHOCK | RockShox Super Deluxe Ultimate RC2T, DebonAir+, Fast Black coating, adjustable rebound, low and high speed compression adjustment, 230 x 57.5mm, custom tuned for Whyte | BOTTOM BRACKET | SRAM DUB, BSA, 73mm |
|---|
| HEADSET | ZS56 upper / lower headset cups for 1 1/18in upper and 1.5in lower with sealed bearings | SEATPOST | TranzX dropper post, 30.9mm, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm drop) |
|---|
| REAR HUB | Alloy, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree Micro Engagement, four pawl, XD Driver, 32 hole | SEAT | Whyte Custom |
|---|
| FRONT HUB | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost thru axle, 32 hole | BAR | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
|---|
| SPOKES | Pillar 2.0mm, black stainless, brass nipples | STEM | Whyte, 35mm extension, 35mm bar bore |
|---|
| RIMS | WTB ST Tough i30 TCS 2.0 System, pinned joint, tubeless ready, 32 hole, 29in (front), 27.5in (rear) | GRIPS | Whyte Enduro lock-on |
|---|
| TYRES | Schwalbe Magic Mary Radial 29 x 2.5in Trail, Super Soft (front); Schwalbe Magic Mary Radial 27.5 x 2.5in, Gravity casing, Soft (rear) | BRAKES FRONT | TRP EVO Expert hydraulic disc brake, four piston, sintered metal pads, 203 x 2.3mm rotor, MMX |
|---|
| SHIFT LEVERS | SRAM S200 Eagle Trigger MMX, 12 speed | BRAKES REAR | TRP EVO Expert hydraulic disc brake, four piston, sintered metal pads, 203 x 2.3mm rotor |
|---|
| FRONT MECH | N/A | BRAKE LEVERS | TRP EVO Expert, MMX |
|---|
| REAR MECH | SRAM S100 Eagle, Half-Mount, 12 speed | PEDALS | Fibre reinforced composite platform |
|---|
| WEIGHT | TBC | | |
|---|
