Carbon fiber enduro frame, 165mm rear travel, up to 172mm, mid-pivot, battery intergrated, rear wheel flip chip,shock positon flip chip,inner cablerouting, Boost 12x148mm, 16T idler,with oversized bearings.
Fox 38 P-S 2026, 29 inch, 170mm, Grip, 15X110mm
Fox float P-S 2026, 205X65mm TR Fox factory customized tunned
FSA No.57 Alloy MTB upper44/lower56
12X148mm alloy, black
DJI Avinox Motor System
Motor Specifications
AVINOX M2S
Weight 2.59 kg
Standard output 1300W / 130Nm
Peak (Boost) output 1300W / 150Nm
Noise level ≤45 dBA
Efficiency 84.5% (up from 82%)
Protection IP66
Unassisted pedalling resistance 41% lower than M1
What’s new on the M2S
• 45% higher power density and 21.6% higher torque density versus the M1, in nearly the
same package size
• 84.5% maximum efficiency, up from 82% on the M1, meaning more sustained output
during high-intensity riding
• Noise reduced to ≤45 dBA, with internal gear clatter on descents and rough terrain
significantly reduced
• Unassisted pedalling resistance cut by 41%, so the bike rolls properly when the motor is
off
• IP66 waterproofing with improved connector protection and better cable torsion
resistance
• Boost mode delivers 150Nm for 10 to 60 seconds, activated by holding the left controller
button
• Smooth Shift and Chain Protection supported with SRAM Eagle AXS (powered by
Avinox)
• 10-sensor system reads cadence, torque, speed, gear position, and bike attitude to
deliver power in Auto, Eco, Trail, and Turbo modes
Sram Eagle 70 single-click
Sram Eagle 70 Transmission
Avinox SL Crank 155mm
Sram XS-1270 10-52T
Magura MT5 4-piston, HC lever
Magura MDR-C 6bolts F220/R203mm
Sram Eagle 70 T-type Chain
Sram Eagle 104BCD 34T
Velduro alloy 35mm, 40mm Stem
Velduro Alloy 35D 800L, rise: 20 Handlebar
Velduro enduro grip
Fizik terra aidon X5
Velduro dropper lever
Velduro mechanical dropper 31.6
S-size: 170mm travel M/L/XL-size: 200mm travel
Velduro e-Enduro Alloy, EA-30 Wheels
Maxxis ASSEGAI 29*2.5 3CGrip DD
Maxxis MINION DHR II 27.5*2.4 3CTerra DD
HUB FRONT Alloy, 2 sealed cartridge bearings, 15x110 thru-axle, 32h, straight-pull, 6-bolt
HUB REAR Alloy, 4 sealed cartridge bearings, 148x12 thru-axle, 32h, straight-pull, 6-bolt, 21T
SAPIM e-light J-bend
Alloy,F 29’/R 27.5’, 30mm internal width Rims
